Horizontal and compact

Eurozink Compact H 800

A compact machine for large cross sections, especially suitable for production of elements for log houses.

This very versatile finger jointing machine boasts a range of innovations. It has reinvented the sector of compact finger jointing machines and still remains its most technologically advanced representative. Strong side alignment, exact positionable feed and hydraulic milling stroke will provide advantages that no other machine can.

Setting of this fully PLC controlled finger jointing machine can be executed in the shortest time, supporting highly adaptable, customer oriented production.

Highlights:

  • Small footprint
  • High pressing power
  • Highest productivity
  • Fixed guiding fence
  • Strong side pressure
  • All machining steps without reclamping

Technical data

Eurozink Compact H 800
Width 75 - 330 mm
Width
Thickness 20 - 180 mm
Thickness
Cycles 6 1/min
Cycles
Typical capacity 800 m/h
Typical capacity
Feeding speed 19 m/min
Feeding speed
Diameter of finger cutters 200 mm
Diameter of finger cutters
